SFJ-231 Mass Spectrometer Helium Leak Detector system For Vacuum Industry 220V 1000W

  • 1
  • 2

Brand Name : Wayeal

Model Number : SFJ-231

Certification : ISO90001, CE

Place of Origin : Anhui, China

MOQ : 1 Piece

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 2000 Pieces Per Month

Delivery Time : 15 Days

Packaging Details : 1 Piece Per Wooden Case

Size : 645 x 678 x 965mm

Power : AC220V, 50HZ/60HZ

Product Name : Helium Leak Detector

Detectable Quality : 2,3,4(H2 , He3, He4)

Application : Semiconductor, new energy, vaccum pump, air conditioner

Response Time(s) : <1

Contact Now

SFJ-231 Mass Spectrometer Leak Detector Hellium Leak Detector for Vacuum Industry
Introduction of Helium Leak Detector
SFJ-231 Helium leak detector is an instrument for rapid positioning and quantitative measurement of leakage of sealed containers
Parameters of Helium Leak Detector

SFJ-231 Helium Leak Detector








Performance Indicators

Minimum detectable leak rate
(Pa·m3/s)/ vacuum mode

5.0×10-13

Minimum detectable leak rate
(Pa·m3/s)/ Suction gun mode

5.0×10-9

Response time(s)

<1

Startup time(min)

≤2

Leakage detection range
(Pa·m3/s)

5.0×10-13~1.0×10-3

Leakage rate display range
(Pa·m3/s)

1.0×10-12~1.0×10-3

Maximum allowable leak detection pressure(Pa)

1330

Detectable quality

2,3,4(H2 , He3, He4)











Basic Configuration

Man-machine interface

7 "color LCD Touch Screen

Ion source

2pcs, iridium coated yttrium oxide, automatic switching

I/O Input/output interface

Eight inputs and eight outputs

Communication interface

RS232/485,USB*2

MES interface

Standard

Physical size of instrument
(W)×(D)×(H),mm

645 x 678 x 965mm

Specifications of leak detection port

DN25 KF

Power Supply

AC220V,50HZ/60HZ

Operating temperature

0-40ºC

Power

1000W

Display language

Both Chinese and English

Leakage rate display

Figure, bar chart, curve chart

Features of Helium Leak Detector

1. Original imported molecular pump
2. Double iridium with ion source
3. Clean air circuit system
4. High-speed CPU+IDC
5. Signal multi-stage amplification technology
6. Wireless remote control
7. One-click automatic clearing of helium background;
